Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67

Product Categories

Kronz (guangzhou) Electronics Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67

Name: Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 15 IP67
Brand: KRONZ
Price: 1 USD

Wholesale Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67 from china suppliers

Voltage : 30V

Contact surface material : Brass, gold-plated

Type : M12 connector

Decription : Male flange connectors

Standard : IEC 61076-2-101

Contacts : 0.5m Pre-wired

Contact nut material : Brass, nickle-plated

Brand Name : KRONZ

Model Number : F1208M-0.5R/M16

Certification : CE

Place of Origin : Guangdong, China

MOQ : 50 pieces

Price : Negotiable

Payment Terms : T/T, Western Union,

Supply Ability : 100000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Contact carrier material : PA, black

Contact Now

Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67

Product Specifications

Attribute	Value
Type	M12 connector
Description	Male flange connectors
Voltage	30V
Contacts	0.5m Pre-wired
Standard	IEC 61076-2-101
Contact nut material	Brass, nickel-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black

Product Overview

The M12 panel mounted connector male head provides reliable electronic connections for industrial applications. Featuring a post-installation method for convenient device integration and PCB version design for stable circuit connections.

Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67

Technical Specifications

Standard	IEC 61076-2-101
Contact nut material	Brass, nickel-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	Brass, nickel-plated
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP67

Configuration Details

Pin assignment	Mounting type	Coding	Rated current	Voltage	Cable outlet	Contacts termination	Part No.
	Rear mounting	A	2A	30V	Straight	0.5m Pre-wired	F1208M-0.5R/M16

Key Features

Precise M16 x 1.5 specification for strong compatibility
Excellent durability and anti-interference performance
Stable connections in complex working environments
Ideal for industrial automation and communication equipment
Efficient and reliable connection solution

Product Tags:

Panel Mount M12 Connector

PCB Version M12 Connector Male

Rear Mounting M12 Connector Male
